De Grote Bosatlas is onlosmakelijk verbonden met het aardrijkskundeonderwijs. Maar ook thuis en op het werk heeft de atlas de status van onmisbaar naslagwerk! The equivalent voltage source is a source of 12 V in series with a resistance of 2 k as shown in Fig. The amount of power transferred will depend upon the load resistance.

If load resistance RL is made equal to the internal resistance Ri of the source, then maximum power is transferred to the load RL. This is known as maximum power transfer theorem and can be stated as follows : Maximum power is transferred from a source to a load when the load resistance is made equal to the internal resistance of the source.

This applies to d. Therefore, power delivered to the load depends upon RL. In order to find the value of RL for which the value of P is maximum, it is necessary to differentiate eq. RL and set the result equal to zero. Under such conditions, the load is said to be matched to the source. Electric power systems never operate for maximum power transfer because of low efficiency and high voltage drops between generated voltage and load. However, in the electronic circuits, maximum power transfer is usually desirable.

de grote bosatlas 54e editie pdf converter

For instance, in a public address system, it is desirable to have load i. A generator develops V and has an internal resistance of Find the power delivered to a load of i ii Comment on the result.

Therefore, if too much efficiency is sought, a large number of such devices will have to be connected in series to get the desired output. This will distort the output as well as increase the cost and size of equipment. Thus, it depends upon a particular situation as to what the load should be. If we want to transfer maximum power e. However, if efficiency is more important e. An audio amplifier produces an alternating output of 12 V before the connection to a load.

The amplifier has an equivalent resistance of 15 at the output. What resistance the load need to have to produce maximum power? Also calculate the power output under this condition. In order to produce maximum power, the load e. The equivalent circuit is shown in Fig. For the a. For maximum power transfer, the load impedance should be conjugate of internal impedance i.

ZL should be j This is shown in dotted line in Fig.

The circuit then consists of internal and external resistances only. This is quite logical because power is only consumed in resistances as reactances XL or XC consume no power. Introduction 1. For instance, in the circuit shown in Fig. To understand the use of this theorem, consider the two-terminal circuit shown in Fig.

The circuit enclosed in the dotted box can be replaced by one voltage E0 in series with resistance R0 as shown in Fig. The behaviour at the terminals AB and AB is the same for the two circuits, independent of the values of RL connected across the terminals.

This is the voltage between terminals A and B of the circuit when load RL is removed. The voltage drop across R2 is the desired voltage E0. This is the resistance between terminals A and B with load removed and e.

LAA110 Datasheet PDF

Once the values of E0 and R0 are determined, then the current through the load resistance RL can be found out easily Refer to Fig. It is called Thevenin voltage E0. It is called Thevenin resistance R0. The load current can now be calculated using only Ohms law and it has the same value as the load current in the original circuit.

Using Thevenins theorem, find the current through resistance connected across terminals A and B in the circuit of Fig.

It is the voltage across terminals A and B with resistance removed as shown in Fig. Introduction 17 Fig. It is the resistance between terminals A and B with removed and voltage source short circuited as shown in Fig.

Now, current through resistance connected across terminals A and B can be found by applying Ohms law. Find the Thevenins equivalent circuit for Fig. The Thevenins voltage E0 is the voltage across terminals A and B. This voltage is equal to the voltage across R3. It is because terminals A and B are open circuited and there is no current flowing through R2 and hence no voltage drop across it.

Calculate the value of load resistance RL to which maximum power may be transferred from the circuit shown in Fig. Also find the maximum power. We shall first find Thevenins equivalent circuit to the left of terminals AB in Fig. This shows another advantage of Thevenins equivalent circuit of a network.

Once Thevenins equivalent resistance R0 is calculated, it shows at a glance the condition for maximum power transfer.

Yet Thevenins equivalent circuit conveys another information. Thus referring to Fig. This is not so obvious from the original circuit shown in Fig. Calculate the current in the 50 resistor in the network shown in Fig.

We shall simplify the circuit shown in Fig. The original circuit of Fig. We shall now find Thevenins equivalent circuit to left of YY in Fig.

Therefore, the original circuit reduces to that shown in Fig. The network in the box may contain any number of resistors and e.

But according to Norton, the entire circuit behind terminals A and B can be replaced by a current source of output IN in parallel with a single resistance RN as shown in Fig. The value of IN is determined as mentioned in Nortons theorem.

The resistance RN is the same as Thevenins resistance R0. Once Nortons equivalent circuit is determined [See Fig.


Nortons theorem is converse of Thevenins theorem in that Norton equivalent circuit uses a current generator instead of voltage generator and resistance RN which is the same as R0 in parallel with the generator instead of being in series with it.
